APC AR3100 – NetShelter SX 42u Server Rack

APC AR3100 NetShelter SX 42u Server Rack

Overview

The APC AR3100 NetShelter SX, available through DC Supplies, is the industry-standard 42U server rack enclosure designed to house high-density server, networking, and storage equipment. It addresses the critical requirements of modern data centers by providing a secure, vendor-neutral environment with optimized airflow management. This enclosure solves common infrastructure challenges such as cable congestion and thermal stratification in row-based deployments.

Engineered with 19-inch wide mounting rails, the AR3100 supports a broad range of IT hardware from major manufacturers. It is primarily deployed in enterprise data centers, colocation facilities, and network closets. The enclosure features pre-installed casters and leveling feet, allowing for rapid deployment and precise alignment within a server row.

This unit is compatible with the full ecosystem of APC Schneider Electric cooling and power distribution products. It should not be used in environments where the total static load exceeds 3750 lbs or in specialized outdoor locations, as its IP20 rating is intended for indoor, climate-controlled environments.

Key Features

• 3750 lb static load capacity supports heavy high-density blade chassis.
• Perforated front and rear doors provide over 80% open area for airflow.
• Integrated rear accessory channels allow tool-less mounting of 0U PDUs.
• Quick-release half-height side panels facilitate easy equipment access.
• Numbered U-positions and adjustable rails ensure rapid hardware alignment.

Specifications

FeatureDetailsBrandAPC by Schneider ElectricPart NumberAR3100Product TypeServer Rack EnclosureRack Height42URack Width19" (EIA-310-E Compliant)Static Load Capacity3750 lbs (1700.97 kg)Dynamic Load Capacity2250 lbs (1020.58 kg)Form FactorFloor Standing TowerMaterial14 Gauge Rail / 16 Gauge Post SteelProtection ClassIP20ColorBlackMounting Depth7.50 to 36.02 inches
